API 7K Drilling Rotary Table Manufacturer
Engineering & Manufacturing Standards
Every unit is designed and manufactured in strict compliance with API 7K specifications, ensuring alignment with global drilling industry standards for safety, durability, and performance. This commitment to compliance guarantees seamless integration with existing rig systems and adherence to rigorous operational requirements.
Core Advantages
API 7K Compliance: Fully certified to meet API 7K standards, ensuring compatibility with global rig specifications and regulatory requirements.
Extended Service Life: The combination of high-grade materials, stress-relief annealing, and precision machining minimizes wear and tear, reducing downtime and lifecycle costs.
Customization Capabilities: We offer tailored solutions to match specific operational needs, from modified dimensions to specialized gear configurations, ensuring optimal integration with your rig setup.
Designed to be the workhorse of your drilling operation, our rotary table combines robust engineering with precision manufacturing—delivering the power, stability, and durability needed to keep drilling operations running efficiently, shift after shift.
Drilling Rotary Table Specifications
Model |
ZP375 |
ZP275 |
ZP205 |
ZP175 |
Max. Static Load |
5850 kN (650 US ton) |
4500 kN (500 US ton) |
3150 kN (350 US ton) |
2250 kN (250 US ton) |
Through Hole Diameter |
952.5 mm (37-1/2 in) |
698.5 mm (27-1/2 in) |
520.7 mm (20-1/2 in) |
444.5 mm (17-1/2 in) |
Gear Ratio |
3.56 |
3.67 |
3.22 |
3.58 |
Distance from Center of Rotary Table to Center of Inner Row of Sprocket Teeth |
1353 mm (53-1/4 in) |
1353 mm (53-1/4 in) |
1353 mm (53-1/4 in) |
1118 mm (44 in) |
Weight |
8026 kg (17694 lb) |
6203 kg (13680 lb) |
5530 kg (12190 lb) |
3888 kg (8572 lb) |
Size (L x W x H) |
2468 x 1810 x 718 mm (97 x 71 x 28 in) |
2392 x 1670 x 685 mm (94 x 66 x 27 in) |
2392 x 1475 x 668 mm (90 x 58 x 26 in) |
1935 x 1280 x 585 mm (76 x 50 x 23 in) |
